Industrial-grade UV flatbed printer combining high precision, speed, and multi-material compatibility to unleash your creativity
The H1000 combines precision engineering with intelligent control systems to deliver exceptional printing solutions for various industries. It achieves high-precision, high-quality direct printing on materials like glass, acrylic, wood, metal, and plastic.
2.5*1.25m hard-anodized vacuum platen, compatible with most flatbed printing media on the market.
Up to 3 rows of Ricoh printheads, 2 rows of Konica, and 2 rows of Epson.
Y-axis features screw drive for high precision and rigidity.
Discover H1000's revolutionary technology for an unparalleled printing experience
The DOCAN H1000 flatbed printer features an all-steel quenched body with a one-piece design for exceptional durability and stability.
The CCD vision-guided system automatically aligns printing materials for automated detection and printing, enhancing production efficiency and print accuracy.
Equipped with imported THK linear guides (Japan), X-axis linear motors, and high-precision metal gratings for pinpoint accuracy and smooth operation.
Explore H1000's detailed technical specifications to meet your professional needs
| Print Area | 2500mm×1250mm |
| Print Height | Max 100mm |
| Resolution | Up to 726×1440 dpi |
| Print Speed | Ricoh Gen6(5PL): 4Pass(3 Row): 50~60sqm/h 6Pass(3 Row): 36~42sqm/h 8Pass(3 Row): 27~30sqm/h Konica 1024A(6PL): 4Pass(2 Row): 33~40sqm/h 6Pass(2 Row): 30~36sqm/h 8Pass(2 Row): 24~28sqm/h Epson T3200: 4Pass(2 Row): 48sqm/h 4Pass(2 Row): 38sqm/h 4Pass(2 Row): 28sqm/h |
| Print Head | Ricoh Gen6(5PL), Konica 1024A(6PL), Epson T3200 |
| Head Quantity | Ricoh Gen6(5PL): 2~12pcs Konica 1024A(6PL): 4~12pcs Epson T3200: 2~4pcs |
| Ink Colors | CMYK/LC/LM+W+V |
| Curing Method | UV LED |
| File Formats | TIFF, JPEG, EPS, PDF |
| RIP Software | SAI/ONYX/Caldera |
| Power Requirements | AC 220V 50/60Hz 10kW 45A |
| Environment | Temperature: 20°C~28°C Humidity: 40%~60% |
| Ink Tank Capacity | 2L |
| Dimensions | 4700mm × 2100mm × 1400mm (without computer stand) 4700mm × 2600mm × 1400mm (with computer stand) |
| Weight | 1510kg |
